With its high thermal sensitivity of NETD < 20mK and 384 VOx sensor, the HIKMCRO LYNX LH19 2.0 ensures the production of harmonious and detailed images. Experience control with the manual focus feature, allowing you to precisely adjust the image to the exact distance.
Key Features
High sensitivity thermal module NETD < 20 mK (@25°C, F# = 1.0)
384 × 288 resolution with 12µm detector
1024 × 768 resolution 0.39-inch OLED display
Replaceable and rechargeable Li-ion battery 280 g lightweight, with a compact and ergonomic design
Up to 6.5 hours of continuous operation
Specifications
Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Max. Resolution 384x288
Frame Rate 50Hz
Pixel Interval 12µm
Response Waveband 8µm to 14µm
NETD Less than 20 mK (@25°C),F#=1.0
Lens (Focal Length) 19mm, F1.0
Detection Range 900m
Focus Mode Focus Ring
Field of View(H × V), Degrees / m @100m 13.7°×10.3°/24.0m×18.0m
Min. Focusing Distance 1.9m
Magnification 1.8x-14.4x (8x)
Image Display
Display 1024x768, 0.39 inch, OLED
Contrast Adjustment Yes
Brightness Adjustment Yes
Palettes Black hot, white hot, red hot, fusion
FFC (Flat Field Correction) Mode Auto, Manual, External Correction
Exit Pupil 6mm
Eye Relief 20mm
Diopter (Range) -5D to +3D
Tone Adjustment Cold, Warm
General
Protection Level IP67
Weight 272g without battery
Dimension 164.0mm × 56.0mm× 60.8mm
Working Temperature -30°C to +55°C
System
Record Video Yes
Capture Snapshot Yes
Hotspot Yes
Standby Mode Yes
Storage Built-in EMMC (16 GB)
PIP Yes
Hot Track Yes
Distance Measurement Yes
Audio Recording Yes
Power Supply
Battery Type Replaceable and Rechargeable Li-ion Battery
Battery Operating Time 6.5-hour continuous running with CVBS and hotspot function off (@25°C)
Type-C Power Supply 5V DC, 2 A, Supports External Power Supply
