Full Colour 4K UHD Brings Vivid Images Even at Twilight
The high-tech Full-Colour 4K UHD detector of HABROK 4K brings crystal clarity during daytime, even at twilight, providing the extra few minutes you need on a hunt.
HABROK 4K delivers the highest level of detail and reproduces colours with natural fidelity.
5.5-22X60 Covers Your Various Observation Needs
Instead of a fixed magnification by optical binocular, the 5.5x-22x magnification with a 60mm focal length means you can zoom HABROK 4K in and out freely from catching whole surroundings to recognizing the smallest details, such as a deer’s antler, or sexuality features, within 150m during daytime
Built-in IR Emitter Brings Superior Clarity in B/W in Darkness
The Built-in IR illuminator brings classic black/white images at night. With optional 850nm or 940nm wavelength and 3-level adjustable emitter power, users are able to see extra miles with superior clarity in total darkness
Quick Scan and Search with Thermal Technology
As a Multi-Spectrum Binocular, HABROK 4K’s thermal camera provides the ability to see through animal’s camouflages and present the animal’s heat signal even when they are among brushes or leaves. Therefore enables a quick scan and search efficiency in open wilds.
Built-in Laser Rangefinder for Accurate Distance Measurement
The integrated laser rangefinder in the HIKMICRO HABROK 4K determines the accurate distances up to a maximum of 1,000m with a ±1 meter accuracy.
Intuitive And Precise Focus for Both Thermal And Digital Viewing
Multi-Spectrum Binocular HABROK 4K provides impressive details even in difficult terrain thanks to the focus ring for both thermal and digital lenses. You can focus with extreme precision even when wearing gloves.
Compact, Lightweight And Robust
Maintaining the classic daytime binocular appearance and lightweight <800g, HABROK 4K is easy to fit into any bag. Besides, the rugged magnesium housing also enhances durability and longevity.
Highlights Capturing in Local Album and APP
One big joy of hunting trips is to record your fascinating and unpredicted adventures instantly. With HIKMICO HABROK 4K, you are able to create photos and videos of your exciting highlights with one press and save them in Local Album and SIGHT APP, no wonderful moments will missed.
Specification
Thermal Module
Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 256 × 192
Frame Rate: 50 Hz
Pixel Interval: 12 µm
Response Waveband: 8 µm to 14 µm
NETD: Less than 35 mK (@25°C), F# = 1.0
Lens (Focal Length): 25 mm, F1.0
Focus Mode: Focus Ring
Detection Range: 1200 m
Min. Focusing Distance: 3 m
Magnification: 4.3x to 17.2x (4x)
Field of View (H × V): 7.0° × 5.3°/12.2 m × 9.3 m @100m
Optical Module
Image Sensor: 1.88’’ Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Focal Length: 60 mm, F2.2
Min. Working Distance: 8 m
Focus Mode: Focus Ring
Magnification: 5.5x to 22.0x(4x)
Field of View (H × V): 6.9°× 4.1°/12.0 m × 7.2 m @100 m
Smart IR: Yes
IR Illuminator Wavelength: 850 nm
Viewing Range at Night: 400 m
Image Display
Display: 0.49 inch, OLED, 1920 ×1080
Palettes: Thermal (Black Hot, White Hot, Red Hot, Fusion); Optical (Day, Night, Auto)
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Exit Pupil: 8 mm
Eye Relief: 15 mm
Diopter (Range): -5 D to +3 D
Brightness Adjustment: Yes
Tone Adjustment: Cold, warm
Contrast Adjustment: Yes
Zoom Pro: Yes
System
Record Video: Yes
Capture Snapshot: Yes
Audio Recording: Yes
Standby Mode: Yes
Storage: Built-in EMMC (64 GB)
PIP: Yes
Hotspot: Yes
Hot Track: Yes
Digital Magnetic Compass: Yes
GPS: Yes
Local Album: Yes
Power Supply
Battery Type: Replaceable and Rechargeable Li-ion Battery
Battery Operating Time: = 8 h (25°C, with hotspot off)
Type-C Power Supply: 5 VDC, 2 A
Supports External Power Supply: Yes
General
Protection Level: IP67
Dimension: 138 mm × 68.2 mm × 223 mm (5.4" × 2.7" × 8.6")
Working Temperature: -30°C to +55°C
Weight: 795 g without batteries
Interpupillary Adjustment Range: 60 mm to 74 mm
Mounting Adapter: 1/4“-20-UNC
Laser Rangefinder
Safety Class for Laser: Class 1
Wavelength: 905 nm
Max. Measuring Range: 1000 m
Measurement Accuracy: ±1 m
Min. Measuring Range: 10 m
