OM System 17mm F1.8 ED II M.Zuiko

17mm F1.8 ED II M.Zuiko

OM SYSTEM Expands Prime Lens Lineup with the Splash & Dust-Proof M.ZUIKO DIGITAL 17mm F1.8 II
Versatile Lenses Designed for Landscapes, City Snapshots, and Portraits


Designed to combine exceptional imaging performance with robust splash and dust-proof durability, the 17mm F1.8 II are compact and lightweight,
making them the perfect companions for photographers on the go.
With its wide f/1.8 apertures and versatile focal lengths, this lens is well-suited for capturing stunning landscapes, dynamic cityscapes, and striking portraits.

The combination of cutting-edge optical technology, intuitive handling, and weather-sealed construction makes these lenses invaluable tools for photographers
seeking creative flexibility and uncompromising reliability

Key Features of the Prime Lens M.ZUIKO DIGITAL 17mm F1.8 II Series:
Wide-angle lens with a large-diameter f/1.8 aperture for stunning bokeh and pan-focus capabilities
IPX1-rated splash-proof performance and dust-proof design for reliable performance in challenging environments
The combination of cutting-edge optical technology, intuitive handling, and weather-sealed construction makes these lenses invaluable tools for photographers seeking
creative flexibility and uncompromising reliability.



M.ZUIKO DIGITAL 17mm F1.8 II
The 17mm F1.8 II lens delivers superb optical performance in a compact, lightweight body measuring just 37.6mm in length and weighing 112 g.

It features a high-precision configuration of nine elements in six groups, including a DSA (Dual Super Aspheric) lens and HR (High Refractive index) lens.
The ZERO (Zuiko Extra-low Reflection Optical) coating reduces ghosting and flaring, ensuring crisp, clear images even in challenging lighting conditions.

Creative Aperture Control: The wide F1.8 aperture allows for stunning bokeh effects, making subjects stand out, while the deep depth
of field typical of wide-angle lenses enables sharp focus across the entire frame, from foreground to background.
Weather-Resistant Durability: With IPX1-rated splash-proof performance and dust-resistant design, photographers can confidently shoot in
adverse weather without worrying about their equipment.



Designed for Every Photographer
The lens offers fast, quiet autofocus (AF) thanks to a MSC (Movie & Still Compatible) mechanism.

Combined with the high-performance image stabilization of OM SYSTEM camera bodies, these lenses make capturing sharp, professional-quality stills and videos effortless









Specifications


FOCAL LENGTH:
17 mm

35MM EQUIVALENT FOCAL LENGTH:
34 mm

LENS CONSTRUCTION:
9 elements in 6 groups (1 DSA lens, 1 HR lens, 2 Aspherical leses)

SPLASHPROOF TYPE / DUSTPROOF:
Standard publication 60529 IPX1 (applies when the lens is used with OM SYSTEM splashproof Body)

ANGLE OF VIEW:
65 degrees

CLOSEST FOCUSING DISTANCE:
0.25 m

MAXIMUM IMAGE MAGNIFICATION:
0.08×

35MM EQUIVALENT MAX. IMAGE MAGNIFICATION:
0.16×

MINIMUM FIELD SIZE:
216 × 162 mm

NUMBER OF BLADES:
7 (circular aperture diaphragm)

MAXIMUM APERTURE:
F1.8

MINIMUM APERTURE:
F22

LENS IS MECHANISM:
No

FILTER SIZE:
Diameter 46 mm

Dimensions


Size D x L (mm):
Ø57.6 × 37.6

Weight (g):
112 (without Lens Cap, Lens Rear Cap and Lens Hood)

Whats in the box
LH-49B Lens Hood
LC-46 Lens Cap
LR-2 Lens Rear Cap
Instruction Manual
Warranty Card
