The HIKMICRO Lynx LC06 Hand Held Thermal is a small compact unit that can easily be carried around in your pocket for ease of use. The Lynx has a 160x120 17 Micron Thermal Core and an extreme wide Field of View. This makes the Lynx a perfect entry level thermal imager for spotting wildlife in the garden or spotting rats and rabbits at close ranges.
The Lynx 6mm comes with a 160x120px, 17µm thermal sensor (35mK NETD Rating) and HIK software deliver a detailed image to the screen. The 35mK NETD Rating equals one of the most sensitive sensors available on the market, detecting even the smallest temperature differences whether it be in rain, fog or snow.
The WiFi and the dedicated app allow you to take complete control of the unit's settings and features from your smartphone so you can share your footage to friends and on social media. The IP67 rating guarantees a robust chassis capable of repelling dust and rain, protecting you from the worst of the weather.
Lynx 6mm comes with a battery life of up to 10 hours which is perfect for long evenings out whether that be deer stalking, vermin control or foxing.
Key Features:
High sensitivity thermal module with 160 x 120 resolution
NETD < 35 mK (@25 ° C F#=1.1)
Leading thermal image processing technology: Adaptive AGC, DDE, 3D DNR
720 × 540 resolution 0.2-inch LCOS display
Built-in rechargeable lithium battery
Up to 10 hours continuous operation
Wi-Fi hot spot
Type-C Interface
Specifications:
Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Resolution 160 × 120
Frame Frequency 50 Hz
Pixel Interval 17 µm
Response Waveband 8 µm to 14 µm
NETD Less than 35 mK (@25°C),F#=1.1
Focal Length 6.2 mm
IFOV 2.74 mrad
Field of View 24.7° × 18.7° (H × V)
Aperture F1.1
Image Display
Monitor 0.2 inch, LCOS, 720 × 540
Palettes Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode Auto, Manual, External Correction
Digital Zoom 1 ×, 2 ×, 4 ×
Smart Function
Hot Track Yes
Detection Range 219 m
System
Storage Built-in memory module (8 GB)
Record Video Yes
Capture Snapshot Yes
Wi-Fi Yes
Standby Mode Yes
Power Supply
Battery Type Rechargeable Lithium Battery
Battery Operating Time
10 hours continuous running with CVBS and Wi-Fi hot spot off (@25°C)
7.5 hours continuous running with CVBS and Wi-Fi hot spot on (@25°C)
Battery Capacity Display Yes
General
Power 5 VDC/2 A, 1.5 W, Type-C Interface
Work Temperature/Humidity From -20 °C to 55 °C (-4 °F to 131 °F); Humidity: 90% or Less
Protection Level IP67
Dimension 158.3 mm × 61 mm × 57 mm
Weight 250 g
